Supply High Torque 2.2kw Spindle Motor with Maximum Torque 0.88Nm and ER20 Collect

Name: Supply High Torque 22kw Spindle Motor with Maximum Torque 088Nm and ER20 Collect
Brand: changsheng
Price: 140.00 USD

Wholesale Supply High Torque 2.2kw Spindle Motor with Maximum Torque 0.88Nm and ER20 Collect from china suppliers

Place of Origin : Jiangsu, China

Applicable Industries : Energy & Mining

Showroom Location : None

Video outgoing-inspection : Provided

Machinery Test Report : Provided

Marketing Type : Ordinary Product

Brand Name : changsheng

Model Number : GDZ80*73-2.2

Application : Milling, Woodworking engraving and milling

Maximum Torque : 0.88Nm

Drive : Inverter

Operating Speed : 24000rpm

Warranty : 1 Year

Core Components : Motor

Brand : Changsheng

Power : 2.2kw

Voltage : 220v or 380v

Frequency : 400HZ

Current : 8A

Specification : 80*73

Collect : ER20

Cooling system : Fan cooling

Net weight : 5.0kg

After Warranty Service : Online support

Local Service Location : None

After-sales Service Provided : Online support

Packaging Details : Customized

Supply Ability : 3000 Piece/Pieces per Month

Price : $140.00/pieces 1-1 pieces

MOQ : 1pc

Delivery Time : 5-8 days

Payment Terms : L/C,T/T

Contact Now

Factory supply high torque 2.2kw spindle motor

Supply High Torque 2.2kw Spindle Motor with Maximum Torque 0.88Nm and ER20 Collect

Product details

Supply High Torque 2.2kw Spindle Motor with Maximum Torque 0.88Nm and ER20 Collect

Product parameter

Model	Power	Voltage	Specification	Speed	Frequency	Collect	Bearings
GDZ80x73-2.2	2.2kw	220v	80*73mm	24000rpm	400Hz	ER20	4
GDZ80-73-2.2	2.2kw	380v	80*73mm	24000rpm	400Hz	ER20	4

Supply High Torque 2.2kw Spindle Motor with Maximum Torque 0.88Nm and ER20 Collect

Model	Power	Voltage	Specification	Speed	Frequency	Collect	Bearings
GDZ93x82-2.2	2.2kw	220v	93*82mm	18000rpm	300Hz	ER25	4
GDZ93-82--2.2	2.2kw	380v	93*82mm	18000rpm	300Hz	ER25	4

Supply High Torque 2.2kw Spindle Motor with Maximum Torque 0.88Nm and ER20 Collect

Product feature

Supply High Torque 2.2kw Spindle Motor with Maximum Torque 0.88Nm and ER20 Collect

Accessories

We can also provide a series of producrs,including inverters,wires,wrenches.

Supply High Torque 2.2kw Spindle Motor with Maximum Torque 0.88Nm and ER20 Collect

If you need other type power spindle , Please fee free to contact us

Water cooling spindle :1.5kw 2.2kw 3.2kw 4.5kw 5.5kw 800w ,

Air cooling spindle :750w 1.5kw 2kw 3.5kw 4.5kw 6kw 7.5kw

Supply High Torque 2.2kw Spindle Motor with Maximum Torque 0.88Nm and ER20 Collect

Our advantage

Supply High Torque 2.2kw Spindle Motor with Maximum Torque 0.88Nm and ER20 Collect

Packing and shipping

As your demand , also determined by your quanity

Supply High Torque 2.2kw Spindle Motor with Maximum Torque 0.88Nm and ER20 Collect

Supply High Torque 2.2kw Spindle Motor with Maximum Torque 0.88Nm and ER20 Collect Images
